MacGregor 24
 | |
| Development | |
|---|---|
| Designer | Roger MacGregor |
| Location | United States |
| Year | 1971 |
| Builder(s) | MacGregor Yacht Corporation |
| Name | MacGregor 24 |
| Boat | |
| Displacement | 2,100 lb (953 kg) |
| Draft | 5.00 ft (1.52 m) with the centerboard down |
| Hull | |
| Type | Monohull |
| Construction | Fiberglass |
| LOA | 24.58 ft (7.49 m) |
| LWL | 21.33 ft (6.50 m) |
| Beam | 7.92 ft (2.41 m) |
| Engine type | Outboard motor |
| Hull appendages | |
| Keel/board type | centerboard |
| Ballast | 575 lb (261 kg) |
| Rudder(s) | transom-mounted rudder |
| Rig | |
| Rig type | Bermuda rig |
| Sails | |
| Sailplan | Fractional rigged sloop |
| Total sail area | 231 sq ft (21.5 m2) |
The MacGregor 24 is an American trailerable sailboat that was designed by Roger MacGregor and first built in 1971.[1][2][3]
Production
The design was built by the MacGregor Yacht Corporation in the United States, but it is now out of production.[1][3][4]
Design
The MacGregor 24 is a small recreational keelboat, built predominantly of fiberglass, with wood trim. It has a fractional sloop, a raked stem, a vertical transom, a transom-hung rudder controlled by a tiller and a retractable centerboard type keel. It displaces 2,100 lb (953 kg) and carries 575 lb (261 kg) of ballast.[1][3]
The boat has a draft of 5.00 ft (1.52 m) with the centreboard extended and 1.50 ft (0.46 m) with it retracted, allowing beaching or ground transportation on a trailer.[1][3]
The boat is normally fitted with a small outboard motor for docking and maneuvering.[1][3]
The design has a hull speed of 6.19 kn (11.46 km/h).[3][5]
