Sisu A2045

"A2045" redirects here. For the road in Great Britain, see A roads in Zone 2 of the Great Britain numbering scheme.

SISU A2045
Sisu A2045
Place of origin Finland
Service history
Used byFinland
Production history
ManufacturerSisu Auto, Karis of Raseborg[1]
No. built234 (FDF orders 2009-2010)[2][3]
Specifications
Mass7.4 t (16,000 lb) (empty)
13.4 t (30,000 lb) (full weight)
Length6.45 m (21 ft 2 in)
 length3.25 m (10 ft 8 in) (wheelbase)
Width2.44 m (8 ft 0 in)
Height3.05 m (10 ft 0 in)
Crew1+2, option for extra 12 persons outside the driver's cabin
ArmorSTANAG 4569
Ballistic level 1
Engine6.87 L 6-cyl MAN D0836 LFL63 Euro 5 Turbo Diesel[4]
184 kW (250 hp), 1,000 Nm
Payload capacity6 t (13,000 lb)
Transmission9-port manual ZF 9S 1310OD or 12-port automatic ZF 12 AS 1210 OD MAN TipMatic
Suspension4×4 wheeled, axles: MAN VP06 front, HPO 728 rear[5]
Ground clearance.35m
Fuel capacity300 L (79 US gal; 66 imp gal)
Operational
range
500 km (310 mi)
Maximum speed 105 km/h (65 mph)

The Sisu A2045 HMTV (High Mobility Terrain Vehicle) is a Finnish standard medium tactical truck, intended to replace older SISU A45 "Proto" light trucks in the Finnish Defence Forces. In spoken language Sisu A2045 is called the MAN-Sisu referring to the engine, axles and other elementary parts delivered by the German lorry manufacturer MAN Nutzfahrzeuge,[6] officially MAN SE, former MAN AG. For the personal transportation on the installed seats, twelve persons can travel outside the driver's cabin. The lorry is classified by its weight as a middle off-road logistic vehicle.

The trucks are used for general logistics and conscript training, as well as for towing artillery pieces, anti-aircraft weapons and command modules.

Sisu A2045 is the successor of Sisu A-45, Sisu AH-45 and Sisu KB-45. The A2045 was introduced at the Security and Defence 2008 exhibition in Lahti, Finland.[7]

Operators

  •  Finland: The Finnish Defence Forces has ordered 232 4×4 vehicles for delivery 2009–2010. It has also an option for an additional 240 vehicles to be bought after 2010.
  • Side view
    Side view
  • Troop compartment
    Troop compartment
  • Towing mortar
    Towing mortar

References

  1. ^ "Sisu toimittaa Puolustusvoimille yli 80 järeää maastokuorma-autoa" (in Finnish). Archived from the original on 4 September 2011. Retrieved 10 May 2011.
  2. ^ "Etusivu".
  3. ^ "Arkisto, Auto, tekniikka ja kuljetus".
  4. ^ "High Mobility Terrain Vehicle SISU A2045".
  5. ^ "Armeija marssii vatsallaan…tai vaihtoehtoisesti Sisulla" (in Finnish). Archived from the original on 23 March 2012. Retrieved 2 December 2012.
  6. ^ "Tällainen on Proto-Sisun seuraaja" (in Finnish).
  7. ^ "SISU A2045 4×4 off-road logistic vehicle introduced at Security and Defence 2008 exhibition". Sisu Defence. Retrieved 30 May 2012.
